Atlas Copco Check Valve Kit GA30–45 Replacement – 2901021200

Atlas Copco 2901021200 – Check Valve Kit GA30–45

The Atlas Copco 2901021200 (2901-0212-00) Check Valve Kit is a service and maintenance kit used in the compressed-air and oil-separation circuit of Atlas Copco GA30–45 oil-injected rotary screw compressors. Its primary function is to permit fluid or compressed-air flow in the required direction while preventing reverse flow when compressor operating conditions change.

Working Process:

During normal compressor operation, compressed air and associated pressure are generated by the screw compressor element and directed through the compressor’s internal flow circuit. The check valve remains in the correct open condition when the upstream pressure is higher than the downstream pressure.

The pressure difference acts against the valve spring and moves the valve element away from its seating surface. This creates an open flow passage and allows the required compressed air or fluid to pass through the valve.

As the pressure conditions change, the spring and valve element continuously respond to the pressure differential. When the upstream pressure falls below the downstream pressure, the spring forces the valve element back onto its seat.

This closes the passage and prevents compressed air or oil from flowing backward through the compressor circuit.

The non-return function is particularly important during compressor unloading and shutdown. When the compressor stops producing pressure, downstream pressure can remain present in the air system. Without a properly functioning check valve, this pressure could flow backward into the compressor and associated internal components.

By preventing reverse flow, the check valve helps protect the compressor circuit, maintain pressure separation, and support correct compressor starting and stopping sequences.

The 2901021200 kit is designed to restore the sealing and mechanical operation of the check valve when its internal components become worn, contaminated, or damaged. Atlas Copco officially identifies the part as “CHECK VALVE KIT GA30-45” for oil-injected screw compressors. The official kit specification lists a 136 g weight and includes a valve, spring, gasket, O-rings, and sealing washers.

Kit Components:

• Valve – 1 piece
• Spring – 1 piece
• Gasket 17 × 21 × 1.5 – 1 piece
• O-ring – 1 piece
• O-ring 69.5 × 3 – 3 pieces
• O-ring 59.5 × 3 – 2 pieces
• Dowty seal washer 1/2+ – 2 pieces

During maintenance, the compressor must be stopped, isolated, completely depressurized, and allowed to cool before the check-valve assembly is serviced.

The valve housing should be opened according to the applicable Atlas Copco service procedure. The old valve, spring, seals, and sealing components should be removed and inspected for wear, deformation, contamination, corrosion, or damage.

The valve seat and internal passages should be thoroughly cleaned. The replacement components supplied in the 2901021200 kit should then be installed in the correct orientation.

The O-rings and sealing washers are particularly important because they prevent leakage around the valve assembly. Correct installation and proper sealing ensure that the valve responds accurately to pressure changes.

After reassembly, the compressor should be tested through its complete start-up, loaded operation, unloading, and shutdown sequence. The check valve should allow flow in the intended direction and close effectively when reverse pressure is applied.

A worn or damaged check valve can cause reverse airflow, pressure loss, difficult restarting, unstable compressor operation, oil migration, leakage, or increased mechanical stress on internal components.

If the valve remains partially open when it should be closed, downstream pressure may return toward the compressor. If it becomes stuck closed, the required flow path may be restricted, causing abnormal pressure conditions and reduced compressor performance.

Correct maintenance using the 2901021200 Check Valve Kit helps restore one-way flow control, prevent reverse pressure, protect internal compressor components, maintain stable pressure conditions, and ensure reliable compressor operation.

Part Number: 2901021200
Alternative Number: 2901-0212-00 / 2901 0212 00
Brand: Atlas Copco
Part Description: Check Valve Kit GA30–45
Component Type: Check / non-return valve service kit
Application: Atlas Copco oil-injected screw compressors
Known Application: GA30–45
Official Listed Weight: 136 g
Primary Function: Allows flow in the required direction and prevents reverse flow
Main Components: Valve, spring, O-rings, gasket, and Dowty sealing washers
Main Benefits: Reverse-flow prevention, pressure stability, reliable starting and shutdown, reduced leakage, and protection of compressor components.
