Atlas Copco Separator Replacement – 1622087100

The part number 1622087100 is an Air/Oil Separator Element used in oil-injected rotary screw air compressors, mainly compatible with several Atlas Copco compressor models such as GX/GA series and equivalent machines.

Typical Application
Oil-injected screw compressors
Atlas Copco GX5 / GX7 / GX11
Atlas Copco GA5 / GA7 / GA11
Compatible replacement for some Chicago Pneumatic (CP) compressors

Function of the Oil Separator
In an oil-injected screw compressor:
Oil is injected into the compression chamber for:
lubrication
sealing
cooling
Compressed air leaving the air end contains oil mist.
The air/oil separator removes oil particles from compressed air.
Recovered oil returns to the lubrication circuit.

Technical Specification-
Burst Pressure- 35 bar
Element Collapse pressure- 5 bar
Filtration Media- Borosilicate micro glass fibre 3 µm
Permissible Flow- 120 m3/h
Flow direction- Out-In
Body Height- 210 mm
Total Height- 211 mm
Seal- VITON
Thread- Metric M24X1.5 Female
Product Net Weight- 1 Kg
Working Pressure- 20 bar
Outer Diameter- 96 mm
