Atlas Copco Scavenge Line & Oil Separator Kit Replacement – 2901920050

Atlas Copco 2901920050 – Scavenge Line & Oil Separator Kit

The Atlas Copco 2901920050 (2901-9200-50) Scavenge Kit is a service and replacement kit used in compatible oil-injected rotary screw compressor systems. Parts references associate this part number with the GA55 compressor and describe it as a Scavenge Line & Oil Separator Kit.

Working Process:

During normal operation of an oil-injected screw compressor, a mixture of compressed air and compressor oil leaves the air-end and enters the oil separator system.

The oil separator removes the majority of the oil from the compressed-air stream. The separated oil collects in the lower section of the separator vessel.

A small quantity of oil can remain suspended in the compressed air or collect in areas where it needs to be recovered. The scavenge system returns this recovered oil back to the compressor air-end.

The scavenge line provides the flow path for the recovered oil. The oil is drawn from the separator area through the scavenge circuit and returned to the air-end, where it can be reused for lubrication, cooling and sealing.

The 2901920050 Scavenge Kit maintains this oil-recovery circuit. A parts reference identifies the kit as a Scavenge Line & Oil Separator Kit for the Atlas Copco GA55, with part number 2901 9200 50. It states that the kit includes three O-rings and a check/non-return valve.

The O-rings provide sealing at the connections within the scavenge circuit. They prevent oil or air leakage and maintain the required pressure differential for proper scavenge operation.

The check/non-return valve controls the direction of flow. It allows recovered oil to move in the intended direction toward the air-end while helping prevent reverse flow when pressure conditions change.

During compressor operation, the pressure differential across the oil separator and scavenge circuit creates the conditions required for recovered oil to flow through the scavenge line.

The oil is continuously returned to the air-end instead of being carried out with the compressed air. This helps maintain proper oil circulation and reduces unnecessary oil consumption.

If the scavenge line becomes blocked, restricted or contaminated, recovered oil may not return correctly to the air-end.

This can cause oil to accumulate in the separator system, increase oil carryover, increase oil consumption and reduce compressor efficiency.

If the check valve fails to operate correctly, reverse flow may occur. This can disturb the scavenge pressure balance and allow oil or air to move in the wrong direction.

If an O-ring becomes damaged, hardened or incorrectly installed, leakage can occur. Even a relatively small leak can affect the pressure differential required for effective oil scavenging.

Maintenance Procedure:

Before servicing the scavenge system, the compressor must be stopped, electrically isolated, completely depressurized and allowed to cool according to the applicable Atlas Copco safety procedure.

The scavenge line and associated connections should be inspected for oil leakage, blockage, contamination, cracks, damaged threads and loose connections.

The check/non-return valve should be inspected to ensure that it moves correctly and permits flow only in the intended direction.

The existing O-rings should be replaced with the supplied sealing components. Sealing surfaces must be clean and free from scratches, dirt and contamination.

The scavenge line should be checked for internal blockage or restriction. Any contamination that can interfere with oil return should be removed according to the applicable service procedure.

The components supplied with the 2901920050 Scavenge Kit should be installed in their correct positions and orientations.

After reassembly, all connections should be checked for proper sealing.

The compressor should then be restarted and monitored during unloaded and loaded operation.

The scavenge system should be checked for oil leakage and correct oil return.

Correct operation of the scavenge system helps maintain the oil balance of the compressor, reduce oil carryover and return separated oil to the air-end for reuse.

Using the Atlas Copco 2901920050 Scavenge Kit during appropriate maintenance helps restore sealing, one-way oil-flow control and reliable oil recovery, supporting efficient and dependable compressor operation.

Part Number: 2901920050
Alternative Number: 2901-9200-50 / 2901 9200 50
Brand: Atlas Copco
Part Description: Scavenge Kit
Related Description: Scavenge Line & Oil Separator Kit
Known Application: Atlas Copco GA55
Component Type: Scavenge/oil-recovery service kit
Main Components: 3 O-rings and check/non-return valve
Primary Function: Returns recovered oil from the separator system to the compressor air-end
Secondary Function: Maintains correct one-way flow and sealing in the scavenge circuit
Operating Function: Uses the compressor’s pressure differential to recover separated oil and return it to the air-end
Main Benefits: Reduced oil carryover, improved oil recovery, reduced oil consumption, proper lubrication, and reliable compressor operation.
