Atlas Copco IMD 300 Connection Kit Replacement

The Atlas Copco 2906074800 IMD 300 Connection Kit is a service kit used when servicing or removing the IMD300 dryer assembly from applicable ZT oil-free compressors. The kit provides the required sealing/connection components to disconnect and reconnect the IMD300 system while maintaining proper airtight connections.

The official Atlas Copco listing specifies a kit weight of approximately 181.4 g.

Working Process

1. Compressed-Air Generation – The oil-free compressor produces compressed air.
2. Drying Stage – Air passes through the integrated IMD300 dryer system.
3. Service Isolation – During maintenance, the IMD300 system is isolated and depressurized.
4. Connection Removal – Existing connections are opened to allow the IMD300 assembly to be serviced or slid out.
5. Seal Replacement – The sealing components supplied in 2906074800 are installed.
6. IMD300 Reconnection – The dryer assembly is reconnected using the replacement sealing components.
7. Leak Prevention – New gaskets/seals provide an airtight connection.
8. System Testing – After reassembly, the compressor and dryer are pressurized and checked for leakage and correct operation.

Kit Components

Atlas Copco’s parts documentation lists the following components for 2906 0748 00:

The official Web Shop also lists gasket/sealing components for the kit.

Main Functions

• Supports IMD300 dryer connection/disconnection.
• Provides replacement sealing components.
• Helps maintain airtight connections.
• Reduces the possibility of compressed-air leakage.
• Facilitates IMD300 servicing and removal.
• Supports reliable dryer operation after maintenance.

Possible Problems With Worn Seals/Gaskets

• Compressed-air leakage.
• Pressure loss.
• Reduced dryer performance.
• Increased compressor energy consumption.
• Audible leakage around connections.
• Difficulty maintaining system pressure.

Maintenance / Installation Procedure

1. Shut down the compressor according to the applicable Atlas Copco service procedure.
2. Isolate the electrical supply.
3. Fully depressurize the compressor and dryer system.
4. Allow the equipment to cool.
5. Isolate the IMD300 dryer connections.
6. Remove the existing connection seals/gaskets.
7. Inspect and clean the mating surfaces.
8. Install the new components supplied with 2906074800.
9. Reconnect the IMD300 assembly.
10. Ensure all gaskets and seals are correctly seated.
11. Tighten connections according to the applicable Atlas Copco specifications.
12. Restore the system and gradually pressurize it.
13. Check all serviced connections for leakage.
14. Restart the compressor.
15. Verify normal dryer and compressor operation.

Technical Summary

Recommended catalog title:
Atlas Copco 2906074800 – ZT110–145 IMD300 Connection Kit for Oil-Free Compressors, 2906-0748-00.

Atlas Copco’s parts documentation specifically identifies 2906 0748 00 as the ZT110–145 IMD300 Connect Kit, while another Atlas Copco parts reference describes its purpose as the kit used when sliding the IMD out of the ZT unit.

Compatibility note: Verify the compressor model and serial number before ordering, particularly because IMD300 connection kits are used across different ZT configurations.
