Atlas Copco IMD 260 Rotor Exchange / Inspection Kit Replacement – 2906084000

The Atlas Copco 2906084000 IMD 260 Rotor Inspection Kit is a specialized service kit designed for the inspection and servicing of the IMD 260 rotor assembly used in Atlas Copco oil-free compressor dryer systems. The kit provides replacement sealing components required when the rotor is inspected, serviced or exchanged.

The rotor is an important rotating component of the IMD dryer system. During operation, it participates in the continuous drying and regeneration process. Proper rotor sealing is essential for maintaining the correct airflow path, pressure conditions and efficient dryer performance. The 2906084000 rotor inspection kit helps restore the sealing condition of the rotor assembly during maintenance.

Working Process

1. Compressed-Air Entry – Compressed air enters the IMD dryer after leaving the compressor.
2. Drying Process – The dryer removes moisture from the compressed air using its adsorption system.
3. Rotor Operation – The IMD 260 rotor rotates as part of the drying/regeneration process.
4. Continuous Cycling – Different sections of the rotor participate in drying and regeneration as the rotor turns.
5. Sealing Requirement – O-rings and sealing elements maintain separation between different air passages.
6. Pressure Control – Proper sealing helps maintain the required pressure difference between process and regeneration areas.
7. Component Wear – Seals can deteriorate because of temperature, pressure, movement and long operating hours.
8. Rotor Inspection – During scheduled maintenance, the IMD 260 rotor assembly is inspected for wear, damage and sealing problems.
9. Seal Replacement – The worn sealing components are replaced using the 2906084000 kit.
10. Rotor Reassembly – The rotor is correctly reassembled and returned to service.
11. Leak Testing – The system is pressurized and checked for leakage.
12. Performance Testing – Dryer operation, pressure, temperature and regeneration performance are verified.

Kit Components

Atlas Copco’s official product listing specifies the following components for 2906084000:

Kit weight: approximately 120 g.

Main Functions

• Supports IMD 260 rotor inspection.
• Supports rotor exchange and servicing.
• Replaces worn O-rings and sealing components.
• Helps maintain proper airflow separation.
• Helps prevent internal air leakage.
• Supports correct adsorption and regeneration cycles.
• Helps restore dryer performance after rotor maintenance.
• Supports reliable Atlas Copco oil-free compressor dryer operation.

Typical Problems Requiring Rotor Inspection

A rotor assembly may require inspection when there is:

• Reduced dryer performance.
• Increased pressure dew point.
• Abnormal pressure drop.
• Air leakage between internal passages.
• Poor regeneration.
• Abnormal dryer cycling.
• Worn or damaged sealing components.
• Excessive operating hours.
• Unusual noise or mechanical symptoms.

Maintenance / Inspection Procedure

1. Shut down the compressor and dryer according to the applicable Atlas Copco service procedure.
2. Isolate and lock out the electrical supply.
3. Fully depressurize the system.
4. Allow the equipment to cool.
5. Isolate the relevant compressed-air connections.
6. Access the IMD 260 rotor assembly.
7. Remove the rotor assembly according to the approved service procedure.
8. Inspect the rotor, sealing surfaces and associated components.
9. Remove worn O-rings and seal components.
10. Clean the relevant mating and sealing surfaces.
11. Install the replacement components supplied in 2906084000.
12. Check that each O-ring is correctly positioned.
13. Verify the seal lip is installed correctly.
14. Reinstall the rotor assembly.
15. Check rotor movement and alignment.
16. Reconnect the air system.
17. Gradually pressurize the dryer.
18. Check for internal/external leakage.
19. Start the compressor/dryer.
20. Verify adsorption and regeneration operation.
21. Check pressure, temperature and dew-point performance.
