Atlas Copco Cooler Kit (Air) Replacement – 2906056600

Atlas Copco 2906056600 – Cooler Kit (Air)

The Atlas Copco 2906056600 (2906-0566-00) is a Cooler Kit (Air) used for servicing the applicable compressor air-cooling circuit.

The cooler is responsible for removing heat from the compressed-air stream during compressor operation. Efficient cooling is essential because compression increases air temperature, and excessive compressed-air temperature can reduce compressor efficiency, increase thermal stress and affect downstream equipment.

The 2906056600 kit is used during maintenance to restore the sealing and service condition of the cooler assembly.

Working Process:

During compressor operation, atmospheric air enters the compressor and passes through the compression process.

As the air is compressed, its pressure and temperature increase.

The hot compressed air then passes through the applicable air cooler.

The cooler transfers heat from the compressed air to the cooling medium.

As heat is removed, the compressed-air temperature decreases.

The cooled air then continues through the compressor or downstream air-treatment circuit, depending on the specific compressor configuration.

Maintaining proper cooler performance helps keep the compressor within its intended operating-temperature range.

During scheduled maintenance, the cooler assembly is inspected for contamination, leakage, damaged seals and reduced cooling performance.

The 2906056600 Cooler Kit (Air) is used to replace the applicable service components and restore the cooler’s sealing condition.

Main Functions:

• Supports servicing of the compressor air cooler.
• Removes heat from compressed air.
• Reduces compressed-air temperature.
• Helps maintain stable compressor operating temperature.
• Supports efficient compressor operation.
• Helps prevent excessive thermal stress.
• Restores sealing at cooler connections.
• Helps prevent air leakage.
• Supports reliable long-term compressor operation.

Cooler Operating Cycle:

1. Air Intake: Atmospheric air enters the compressor.
2. Compression: Air pressure and temperature increase.
3. Hot-Air Flow: Heated compressed air reaches the cooler.
4. Cooling: Heat is transferred from the air to the cooling medium.
5. Temperature Reduction: Compressed-air temperature decreases.
6. Conditioned Air: Cooled air continues through the compressor circuit.
7. Continuous Operation: Cooling continues while the compressor is operating.

Importance of the Cooler:

Compression naturally generates heat. If the cooler becomes dirty, restricted or damaged, its ability to remove heat can decrease.

Possible consequences include:

• Increased compressed-air temperature.
• Higher compressor operating temperature.
• Reduced cooling efficiency.
• Increased thermal stress.
• Increased energy consumption.
• High-temperature alarms.
• Reduced compressor performance.
• Possible thermal shutdown.

Regular inspection and servicing of the cooler help maintain effective heat transfer.

Role of the Service Kit:

The cooler service kit provides the applicable replacement components needed during maintenance of the cooler assembly.

A cooler connection must remain properly sealed because leakage can reduce system efficiency and may allow the operating medium to escape.

Replacement sealing components restore the connection between mating surfaces and help maintain pressure integrity.

A correctly serviced cooler therefore provides both:

• Effective heat transfer.
• Reliable leak-tight operation.

Possible Failure Conditions:

Cooler performance can deteriorate because of:

• Dust accumulation.
• Dirt or contamination.
• Fouling of heat-transfer surfaces.
• Restricted airflow.
• Corrosion.
• Mechanical damage.
• Deteriorated sealing components.
• Incorrect assembly.
• Leakage.
• Thermal cycling.

Possible symptoms include:

• High discharge temperature.
• Reduced cooling performance.
• Air leakage.
• High-temperature alarms.
• Increased compressor energy consumption.
• Abnormal operating temperature.
• Reduced compressor efficiency.
• Unexpected shutdown.

These symptoms can also be caused by fans, airflow restrictions, sensors, valves or other cooling-system components, so proper diagnosis is required.

Maintenance Procedure:

Before servicing the cooler, stop the compressor according to the normal shutdown procedure.

Isolate the electrical supply and applicable pneumatic/cooling energy sources.

Depressurize the relevant circuit and allow hot components to cool to a safe working temperature.

Inspect the cooler for:

• Dirt accumulation.
• Blocked passages.
• Corrosion.
• Leakage.
• Damaged seals.
• Damaged connections.
• Mechanical damage.
• Reduced heat-transfer performance.

Remove the applicable old service components.

Clean the cooler and all mating/sealing surfaces according to the applicable Atlas Copco service procedure.

Install the replacement components supplied with the 2906056600 Cooler Kit (Air).

Ensure:

• All sealing components are correctly positioned.
• Seals are not twisted or damaged.
• Mating surfaces are clean.
• Cooling passages are unobstructed.
• Connections are correctly secured.
• No foreign material remains inside the system.

After reassembly, perform the applicable leak and functional checks.

Restart the compressor and allow it to reach normal operating conditions.

Monitor:

• Discharge temperature.
• Cooler performance.
• Airflow.
• Pressure.
• Leakage.
• Abnormal noise.
• Overall compressor stability.

Service Benefits:

Using the Atlas Copco 2906056600 Cooler Kit (Air) during appropriate maintenance helps:

• Restore cooler sealing.
• Maintain effective heat transfer.
• Reduce compressed-air temperature.
• Reduce leakage.
• Control compressor operating temperature.
• Reduce thermal stress.
• Support compressor efficiency.
• Improve equipment reliability.
• Reduce unexpected downtime.

Part Number: 2906056600
Alternative Number: 2906-0566-00 / 2906 0566 00
Brand: Atlas Copco
Official/Parts Description: Cooler Kit (Air) / KIT COOLER AIR
Component Type: Air cooler service kit
Primary Function: Supports servicing of the compressor air-cooling system
Operating Function: Removes heat from compressed air and helps maintain proper operating temperature
Main Benefits: Effective cooling, reliable sealing, controlled temperature and dependable compressor operation.
