Atlas Copco Air Filter Element Replacement – 1613744700

The Atlas Copco 1613744700 is an air filter element used to clean the intake air entering compatible Atlas Copco compressors. Multiple parts references identify 1613-7447-00 as an Atlas Copco air-filter element.

Working Process

The 1613744700 air filter element removes dust, dirt and airborne particles from atmospheric air before the air enters the compressor’s compression system.

During operation, outside air passes through the filter media. Contaminants are trapped by the filter while filtered air continues toward the compressor airend. This protects internal components from abrasive particles and helps maintain efficient compressor operation.

As dust accumulates on the filter, airflow resistance gradually increases. Replacing the filter at the appropriate maintenance interval helps maintain sufficient airflow and prevents excessive pressure drop at the compressor inlet.

Application & Specifications

Available references associate 1613744700 with Atlas Copco applications including GA30, GA37, GA45, ZT15, ZT18, ZT22, ZT30, ZT37 and ZT45, as well as various portable compressor models.

Published dimensions are approximately:

• Outer diameter: 159 mm
• Inner diameter: 101 mm
• Height: 377 mm
• Weight: approximately 0.725 kg

A filter cross-reference document also lists 1613744700 alongside 1613740700, 2903740700, 2914930600 and other equivalent filter references.

Key Benefits

• Removes dust and contaminants from compressor intake air.
• Protects the compressor airend and internal components.
• Helps maintain clean and unrestricted airflow.
• Supports efficient compressor operation.
• Helps reduce abrasive wear.
• Helps maintain stable compressor performance.
• Suitable for scheduled compressor maintenance.
• Available as a replacement air-filter element.

Maintenance Importance

The filter should be inspected regularly and replaced when heavily contaminated or when the compressor indicates excessive intake restriction. Operating with a clogged filter can increase pressure drop and reduce compressor efficiency.
